Stainless steel Cap ASTM A403 WP304/304L, WP316/316L, WP321, WP347,
WPS 31254. UNS S31803, UNS32750, UNS32760
| Brand Name: | TOBO | | Model Number: | A403-WP304 A403-WP304L A403-WP316. A403-WP316L A420-WPL6,316L,
304L, 321, 321H. | | Certification: | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED | | Place of Origin: | China |
|
|
| Product Name | Stainless steel elbow | Product Type | Butt weld elbow |
| Size | 1-48 inch | DN15-DN1200 | 15-1200 |
| Material Grrade | UNS S32750 | Type | Seamless or weld |
| Standard | ASME B16.9, ASME B16.11 | Standard | DIN,EN,ASTM,BS,JIS,GB,etc. |
| Application | Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding
etc |
| Minimum Order Quantity: | 1pcs |
| Price: | Depending on quantity |
| Payment Terms: | T/T or Western Union or LC |
| Supply Ability: | 3,0000pcs per month |
| Delivery Time: | 10-100 days depending on quantity |
| Packaging Details: | PLY-WOODEN CASE OR PALLET |
Specifications
1.Stainless steel elbow
2.sch5s-schxxs
3.ISO9001,ISO9000
4.Market:America,Africa,Middle East,Southeast of Asia
| Elbow Type | Stainless steel elbow ,45/90/180 welded/seamless elbow; return
elbow |
| Standard | ASME/ANSI B16.9 |
| Size | 1/2’’~48’’(Seamless);16’’~72’’(Welded) |
| Wall thickness | Sch5~Sch160XXS |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Material | Carbon steel, stainless steel, alloy steel, duplex stainless,
nickel alloy steel |
| Carbon steel | ASTM A234 WPB, WPC; |
| Stainless steel | 304/SUS304/UNS S30400/1.4301 304L/UNS S30403/1.4306; 304H/UNS S30409/1.4948; 309S/UNS S30908/1.4833 309H/UNS S30909; 310S/UNS S31008/1.4845; 310H/UNS S31009; 316/UNS S31600/1.4401; 316Ti/UNS S31635/1.4571; 316H/UNS S31609/1.4436; 316L/UNS S31603/1.4404; 316LN/UNS S31653; 317/UNS S31700; 317L/UNS S31703/1.4438; 321/UNS S32100/1.4541; 321H/UNS S32109; 347/UNS S34700/1.4550; 347H/UNS S34709/1.4912; 348/UNS S34800; |
| Alloy steel | ASTM A234 WP5/WP9/WP11/WP12/WP22/WP91; ASTM A860 WPHY42/WPHY52/WPHY60/WPHY65; ASTM A420 WPL3/WPL6/WPL9; |
| Duplex steel | ASTM A182 F51/S31803/1.4462; ASTM A182 F53/S2507/S32750/1.4401; ASTM A182 F55/S32760/1.4501/Zeron 100; 2205/F60/S32205; ASTM A182 F44/S31254/254SMO/1.4547; 17-4PH/S17400/1.4542/SUS630/AISI630; F904L/NO8904/1.4539; 725LN/310MoLN/S31050/1.4466 253MA/S30815/1.4835; |
| Nickel alloy steel | Alloy 200/Nickel 200/NO2200/2.4066/ASTM B366 WPN; Alloy 201/Nickel 201/NO2201/2.4068/ASTM B366 WPNL; Alloy 400/Monel 400/NO4400/NS111/2.4360/ASTM B366 WPNC; Alloy K-500/Monel K-500/NO5500/2.475; Alloy 600/Inconel 600/NO6600/NS333/2.4816; Alloy 601/Inconel 601/NO6001/2.4851; Alloy 625/Inconel 625/NO6625/NS336/2.4856; Alloy 718/Inconel 718/NO7718/GH169/GH4169/2.4668; Alloy 800/Incoloy 800/NO8800/1.4876; Alloy 800H/Incoloy 800H/NO8810/1.4958; Alloy 800HT/Incoloy 800HT/NO8811/1.4959; Alloy 825/Incoloy 825/NO8825/2.4858/NS142; Alloy 925/Incoloy 925/NO9925; Hastelloy C/Alloy C/NO6003/2.4869/NS333; Alloy C-276/Hastelloy C-276/N10276/2.4819; Alloy C-4/Hastelloy C-4/NO6455/NS335/2.4610; Alloy C-22/Hastelloy C-22/NO6022/2.4602; Alloy C-2000/Hastelloy C-2000/NO6200/2.4675; Alloy B/Hastelloy B/NS321/N10001; Alloy B-2/Hastelloy B-2/N10665/NS322/2.4617; Alloy B-3/Hastelloy B-3/N10675/2.4600; Alloy X/Hastelloy X/NO6002/2.4665; Alloy G-30/Hastelloy G-30/NO6030/2.4603; Alloy X-750/Inconel X-750/NO7750/GH145/2.4669; Alloy 20/Carpenter 20Cb3/NO8020/NS312/2.4660; Alloy 31/NO8031/1.4562; Alloy 901/NO9901/1.4898; Incoloy 25-6Mo/NO8926/1.4529/Incoloy 926/Alloy 926; Inconel 783/UNS R30783; NAS 254NM/NO8367; Monel 30C Nimonic 80A/Nickel Alloy 80a/UNS N07080/NA20/2.4631/2.4952 Nimonic 263/NO7263 Nimonic 90/UNS NO7090; Incoloy 907/GH907; Nitronic 60/Alloy 218/UNS S21800 |
| Package | Wooden cases, pallets, nylon bags or according to the customers'
requirements |
| MOQ | 1pcs |
| Delivery time | 10-100 days depending on quantity |
| Payment terms | T/T or Western Union or LC |
| Shipment | FOB Tianjin/Shanghai, CFR, CIF, etc |
| Application | Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding
etc |
| Remarks | Other materials and drawings are available. |
Welcome to contact us.
|
Specifications
1.Pipe caps
2.Professional manufacturer (32 years)
3.Fast Delivery
4.Size: 1/2"---68"
5.WT: sch5-sch160 XXS
product name:pipe cap
pipe fittings caps
Size 1/2"-68"DN15-DN1800 Wall thickness Sch5-Sch160XXS Standard ISO, SNSI, JIS, DIN, GB/T12459GB/T13401ASME B16.9SH3408
SH3409HG/T21635HG/T21631SY/T05010 Material A234-WPB.A420-WPL6.A234-WP12.A234-WP11.A234-WP5.A403-WP304.A403-WP304L.
A403-WP316.A403-WP316L Packaging Wooden Cases or wooden pallet or as per customers requirement
Applications range Petroleum, chemical, power, gas, metallurgy,
shipbuilding, construction, etc
Min Order Quantity According to customer's requirement
Delivery Time According to customer's requirement Quality First grade
Productivity 1,118,000T/Y 1. anti-corrosion and high-temperature resistant with black
painting
2. All special design available according to requirementS
3. The production process are made under the ISO9001:2000 strictly. |
Cap
1.Product Details.
Standrad
1 )Standard: ASTM, ASME , DIN ,JIS,API ,GB ,ISO
2) Certifications : ABS ,CC ,TUV,CC ,GL ,BV ,ISO14001 ,ISO9001
,OHSMS
Material :
Carbon Steel: ASTM A-234 (WPB,WPC)
EN 10216-2 (P235GH,P265GH)
EN10222-2(P245GH,P280GH)
NF A49-213 (TU42C,TU48C)
Low Alloy Steel : ASTM A-420(WPL6)
ASTM A-234(WP11,WP22,WP5)
ASTM A-860(A860-WPHY52)
Stainless Steel: ASTMA403M
(WP304,WP304L,WP304H,WP316,WP316L,WP321,WP321H,WP347,WP347H)
EN10216-5(X2CrNiN18-10(1.4311),X5CrNi18-10(1.4301),X5CrNiMo17-12-2(1.4401),X2CrNiMo17-12-2(1.4404)
Standrad
1 )Standard: ASTM, ASME , DIN ,JIS,API ,GB ,ISO
2) Certifications : ABS ,CC ,TUV,CC ,GL ,BV ,ISO14001 ,ISO9001
,OHSMS
Material :
Carbon Steel: ASTM A-234 (WPB,WPC)
EN 10216-2 (P235GH,P265GH)
EN10222-2(P245GH,P280GH)
NF A49-213 (TU42C,TU48C)
Low Alloy Steel : ASTM A-420(WPL6)
ASTM A-234(WP11,WP22,WP5)
ASTM A-860(A860-WPHY52)
Stainless Steel: ASTMA403M
(WP304,WP304L,WP304H,WP316,WP316L,WP321,WP321H,WP347,WP347H)
EN10216-5(X2CrNiN18-10(1.4311),X5CrNi18-10(1.4301),X5CrNiMo17-12-2(1.4401),X2CrNiMo17-12-2(1.4404)
Remarks :
Report Suspicious Activity
Quick Details
| Material: | Stainless Steel | Technics: | But Weld ,Forged | Type: | Cap |
| Place of Origin: | Shanghai China (Mainland) | Model Number: | 1/2"-48" | Brand Name: | TOBO |
| Connection: | SMLS, Welding | Shape: | Round | Head Code: | Round |
| silvery: | silvery | | | | |
Packaging & Delivery
| Packaging Details: | wooden cases or as to per costumer's requirement |
| Delivery Detail: | in 30 days or as to customers' requirements |
Specifications
1)Seamless Pipe Cap
2)Size:DN15-DN700
3)Standard:ASME/DIN/JIS/BS/EN
4)Material:CS/SS
5)0.2--48$/pcs
Seamless Pipe Cap
| Material Code |
| CARBON STEEL | ASTM A234 WPB, WPC; ASTM A420 WPL9, WPL3, WPL6,WPHY-42 |
| WPHY-46, WPHY-52, WPHY-60 WPHY-65, WPHL-70. |
| ALLOY STEEL | ASTM A234 WP1, WP11, WP12, WP22, WP5, WP9, WP91 |
| STAINLESS STEEL | ASTM A403 WP304/304L, WP316/316L, WP321, WP347, WPS 31254 |
| STANDARDS | ANSI, ISO, JIS, DIN, BS, GB, SH, HG, QOST, ETC. |
| CE and certification: | ISO9001:2000, API, BV, SGS, LOIYD |
| Application range: | Petroleum,chemical,power,gas,metallurgy, shipbuilding,Construction,
water and nuclear power etc. |
| The third party | BV, SGS, LOIYD, TUV, and other party alloyed by clients. |
| Delivery time: | At the earliest, within the period required by customers. |
| Remark | Also can supply IBR fittings and Specialized NACE & HIC Fittins. |
| Nominal Diameter | Outside Diameter at Bevel | Back to End | | | Series A | Series B | E | T | E1 | | | DN | NPS | | | 15 | 1/2 | 21.3 | 18 | 25 | 4.57 | 25 | | | 25 | 1 | 33.7 | 32 | 38 | 4.57 | 38 | | | 40 | 1.1/2 | 48.3 | 45 | 38 | 5.08 | 38 | | | 50 | 2 | 60.3 | 57 | 38 | 5.59 | 44 | | | 65 | 2.1/2 | 76.1(73) | 76 | 38 | 7.11 | 51 | | | 80 | 3 | 88.9 | 89 | 51 | 7.62 | 64 | | | 100 | 4 | 114.3 | 108 | 64 | 8.64 | 76 | | | 125 | 5 | 139.7 | 133 | 76 | 9.65 | 89 | | | 150 | 6 | 168.3 | 159 | 89 | 10.92 | 102 | | | 200 | 8 | 219.1 | 219 | 102 | 12.70 | 127 | | | 300 | 12 | 323.9 | 325 | 152 | 12.70 | 178 | | | 350 | 14 | 355.6 | 377 | 165 | 12.70 | 191 | | | 400 | 16 | 406.4 | 426 | 178 | 12.70 | 203 | | | 450 | 18 | 457.2 | 478 | 203 | 12.70 | 229 | | | 500 | 20 | 508.0 | 529 | 229 | 12.70 | 254 | | | 550 | 22 | 559 | - | 254 | 12.70 | 254 | | | 600 | 24 | 610 | 630 | 267 | 12.70 | 305 | | When T is less the dimension in parentheses, the height E is
available. Otherwise E1 is available. Above dimensions acc.to GB/T12459,GB/T13401,ASME
B16.9,SH3408,SH3409,HG/T21635,HG/T21631,SY/T05010 | |
|
