201 / 202 Polished stainless steel pipe welding For Fluid ASTM A249

Ask Lasest Price
Brand Name :	TOBO
Model Number :	ASTM A554, A312, A249, A269 And A270,A688
Certification :	LR,BV,SGS,BIS,DNV,CRN,ABS,TUV，
Price :	1USD
Payment Terms :	TT/LC
Supply Ability :	300000T/Year
Delivery Time :	0-30days

Add to Cart

Product Details
Company Profile

201 / 202 Polished stainless steel pipe welding For Fluid ASTM A249

201 / 202 Polished stainless steel pipe welding For Fluid ASTM A249

Detailed Product Description

Test:	Squash Test, Extended Test, Water Pressure Test, Crystal Rot Test, Heat Treatment, NDT	Application:	Handrail,weldmesh Screen,door,window, Balcony,fence,furniture,etc
Material Grade:	304,316,201,202, 316L,430	Outer Diameter:	6mm-101.6mm
Standard:	ASTM A554, A312, A249, A269 And A270,A688	Surface:	Polished
Type:	Stainless Steel Welded Tube / Pipe	Wall Thickness:	0.6mm-3mm

201 / 202 Polished stainless steel pipe welding For Fluid ASTM A249

Quick Detail:

Welded Stainless Steel tube As per ASTM A249/A269,polished, for fluid and decorative
1 Standard: ASTM A249/269
2 Material:304,316,201,202, 316L,430
3 OD: 6mm-101.6mm
Wall: 0.6mm-3mm
4 Surface:polished

Name	Stainless steel welded tube
Standard	ASTM A554, A312, A249, A269 and A270,A688
Material Grade	304,316,201,202, 316L,430
Size Range	20x10mm--100x50mm,10x10mm-100x100mm, 9.53-101.6mm, we can also accept sizes above 101.6mm
Thickness	0.3mm - 3.0mm
Length	6m or as customers' request
Tolerance	a) Outer Diameter: +/- 0.2mm
	b) Thickness: +/- 0.02mm
	c) Length: +/- 5mm
Surface	180G, 320G Satin / Hairline(Matt Finish, Brush, Dull Finish) 400G, 600G Mirror finish
Application	Handrail,weldmesh screen,door,window, balcony,fence,furniture,etc
Test	Squash test, Extended test, Water pressure test, Crystal rot test, Heat treatment, NDT
Chemical Composition of Material	Composition Material	201	202	304	316L	430
	C	≤0.15	≤0.15	≤0.08	≤0.35	≤0.12
	Si	≤1.00	≤1.00	≤1.00	≤1.00	≤1.00
	Mn	5.5-7.5	7.5-10	≤2.00	≤2.00	≤1.00
	P	≤0.06	≤0.06	≤0.045	≤0.045	≤0.040
	S	≤0.03	≤0.03	≤0.030	≤0.030	≤0.030
	Cr	13-15	14-17	18-20	16-18	16-18
	Ni	0.7-1.1	3.5-4.5	8-10.5	10-14
	Mo				2.0-3.0
Mechanical Property	Material Item		201	202	304	316
	Tensile Strength		≥535	≥520	≥520	≥520
	Yield Strength		≥245	≥205	≥205	≥205
	Extension		≥30%	≥30%	≥35%	≥35%
	Hardness (HV)		<105	<100	<90	<90

The welded stainless steel pipe is made from stainless steel by electric welding or sheet metal strips by means of forming and welding. Electrically welded tube is made of thermally without subsequent processing and hot-reducing.
